Bristan Cruzar 2 Outlet Thermostatic Concealed Shower Valve With Fixed Head And Handset - Brushed Brass

The Bristan Cruzar shower set in brushed brass is a modern and elegant addition designed to enhance contemporary bathroom spaces with both style and functionality. Its refined brushed brass finish and clean modern design create a warm and sophisticated look that complements a wide range of interiors. Designed for wall mounting, this shower set is constructed from a durable combination of brass and ABS, ensuring long lasting strength and reliable performance. It operates efficiently across a wide pressure range from 0.2 bar up to 5 bar, with a maximum static pressure of 10 bar. Supporting hot water temperatures up to 65 degrees, it delivers consistent flow performance through the handset, ranging from 2.58 litres per minute at 0.2 bar up to 9.03 litres per minute at 5 bar, ensuring a comfortable and adaptable showering experience for everyday use.

This shower set features a recessed thermostatic valve with a 40mm single lever cartridge that provides smooth and precise control over water flow and temperature. The thermostatic cartridge includes a preset safety stop at 42 degrees, offering family safe showering by preventing excessively hot water. It is suitable for all plumbing systems and performs best in balanced installations. The integral two outlet diverter allows easy switching between the handset and the drench head, providing flexibility and convenience. The rub clean handset and drench head make maintenance simple, as limescale and debris can be quickly removed by wiping the nozzles. Although no isolation valve is included, the Easyfit installation system ensures a straightforward setup process. Designed for both safety and performance, this shower set is backed by a lifetime guarantee and offers a reliable, stylish solution for modern bathrooms.

PRODUCT SPECIFICATIONS

• Product SKU: CRUZAR BB SHWR PK2
• Shower Set
• Brand: Bristan
• Collection: Cruzar
• Finish: Brushed Brass
• Style: Modern
• Mounting: Wall
• Material: Brass/ABS
• Guarantee: Lifetime
• Inlet Connection: 15mm Compression
• Outlet Connection: G 1/2”
• Minimum Pressure: 0.2 Bar
• Maximum Pressure: 5.0 Bar
• Max. Hot Water Temperature °C: 65°C
• Max. Static Pressure: 10 Bar
• Flow Rate - 0.2 (Handset) Bar: 2.58 L/min
• Flow Rate - 0.5 (Handset) Bar: 4.63 L/min
• Flow Rate - 1 (Handset) Bar: 6.78 L/min
• Flow Rate - 2 (Handset) Bar: 7.8 L/min
• Flow Rate - 3 (Handset) Bar: 8.27 L/min
• Flow Rate - 5 (Handset) Bar: 9.03 L/min
• Isolation Valve Included: No

PRODUCT FEATURES

• Shower Type Recessed Thermostatic Valve
• 40mm Single Lever Cartridge
• Suitable for all plumbing systems, ideally balanced
• Rub clean handset and drench head - limescale and debris build-up is quickly and easily removed by rubbing a finger or a cloth over the nozzles.
• Integral two outlet diverter so you can easily switch between the handset or drench head.
• Thermostatic cartridge with preset temperature safety stop at 42°C for familysafe showering.
• Easyfit Installation

Download the Technical PDF Here.
